AC10-T/S2-R75G-B-VC Variable Frequency Drive AC10 | 0.75 кВт 1ф/220

The Veichi AC10 variable frequency drive (SKU: AC10-T/S2-R75G-B-VC) ensures reliable operation thanks to its compact dimensions (height 177 mm, width 65 mm, depth 148 mm) and built-in control features. The device has a rated power of 0.7 kW, single-phase power supply of 1-f/220 V, and a three-phase output supply voltage of 3-f/220 V, which guarantees stable operation in systems with various modes of operation. The maximum output frequency reaches 600 Hz with a brief peak of 150% and a nominal current of 4 A, contributing to the device's high dynamic response. Built-in PLCs and PID, as well as support for scalar and vector control modes with linear and quadratic U/f laws, provide precise adjustment of the device's parameters. The device can be used to control electric motors in pumping stations, ventilation systems, compressor drives, and rotating mechanisms in production lines. It is applied in the automation systems of technological processes in light and heavy industrial manufacturing enterprises. The product also effectively integrates into energy-saving systems, temperature control, and welding processes. Thanks to its technical characteristics and wide control capabilities, the drive is ideally suited for many areas of application in modern manufacturing and process automation.

Veichi AC10 — compact VFD for pumps, fans and simple drives

AC10 is the smallest drive in the Veichi range. It covers 0.75 to 22 kW and fits in your palm (177×65 mm for the smaller models). We've supplied over 150 units in the last two years — most went to borehole pumps on private properties and small workshop fans.

The main advantage: it runs off a generator without tripping. A built-in kinetic buffer uses the motor's inertia during a voltage dip — the drive doesn't shut down, it just lowers the frequency for a fraction of a second. For farms and sites without a stable grid, that's critical.

What AC10 is good for

• Borehole pumps 0.75–2.2 kW (1ph/220V): the most popular use. Built-in PID holds pressure, sleep mode shuts the pump off once pressure is reached — saving energy and wear. Setup: VFD for a borehole pump.
• Exhaust fans 0.75–7.5 kW: scalar U/f mode, smooth jerk-free start.
• Packaging machines 0.75–4 kW: sensorless vector, 600 Hz max — suits high-speed spindles.
• Woodworking 2.2–7.5 kW: routers, edgebanders — the compact body saves cabinet space.

Comparison with alternatives

Parameter	Veichi AC10	Delta VFD-EL	INVT GD10
Power	0.75–22 kW	0.2–22 kW	0.4–15 kW
Max frequency	600 Hz	400 Hz	400 Hz
Sleep mode (PID)	Yes	No	No
Braking unit	Built-in	External	External

AC10 wins on two things: 600 Hz for high-speed motors and a built-in braking unit (external on Delta and INVT). But if you need CANopen or Profibus — none of AC10, GD10 or VFD-EL have them: then look at the AC310 with expansion cards.

AC10 parameters that save you on commissioning

• Reverse without swapping phases: direction changes in software via F07.05 (units digit = 1 to invert). No need to touch the terminal block. Step by step: motor reverse on Veichi.
• Start from terminals, not the keypad: F01.01=1 moves the RUN command to the control board terminals (then pick 2-/3-wire mode in F05.20), wire the Start button to COM. Remote control.
• External potentiometer: F11.30=1 switches the serial port to an external keypad with a potentiometer (RJ45). While the port is used for the potentiometer, Modbus over RS485 is temporarily unavailable — that's expected. How to connect a potentiometer.
• Auto-restart after a voltage dip: F07.06=1 (on AC10 the range is only 0~1), restart wait time is F07.07 = 0.00–60.00 s. On a generator it keeps the pump running without a manual restart. Auto-restart after E.Lu.
• Braking resistor: for frequent braking the resistance is chosen by power (for 1ph/220V: 0.75 kW ≈200 Ω, 1.5 kW ≈100 Ω, 2.2 kW ≈75 Ω) — this clears the DC-bus overvoltage (E.OU2 on deceleration). Choosing a braking resistor.

When AC10 is NOT the right choice

• Power above 22 kW — you need Veichi AC310 (up to 400 kW)
• Servo, precise positioning — you need a Veichi SD700 servo drive
• Crane, lift, heavy load — Veichi AC70 with STO
• Profibus/CANopen fieldbus — AC310 with expansion cards

Our experience

Motor auto-tuning (parameter F02.07) is probably the handiest feature. It saves about 15 minutes on every commissioning: the drive measures the winding parameters itself, so you don't have to find the nameplate and type values in by hand. On farms with old, undocumented motors that's a lifesaver. The rest of the typical settings are in one place: Veichi basic setup.
